FH19C-6S-0.5SH(05)
Manufacturer:
Hirose Electric
Mfr.Part #:
FH19C-6S-0.5SH(05)
Datasheet:
Description:
FFC / FPC SMD/SMT Number of Positions:6 500 mA 50 V
| Parameter | Value |
|---|---|
| Length | 5 mm |
| Width | 3 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -55 °C |
| Height | 900 µm |
| Packaging | Reel |
| Voltage Rating | 50 V |
| Depth | 3.5 mm |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Lead Pitch | 500 µm |
| REACH SVHC | No SVHC |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 500 µm |
| Current Rating | 500 mA |
| Max Current Rating | 500 mA |
| Flammability Rating | UL94 V-0 |
| Orientation | Right Angle |
| Gender | Receptacle |
| Number of Contacts | 6 |
| Connector Type | Receptacle |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Housing Material | Polymer |
| Contact Resistance | 100 mΩ |
| Max Voltage Rating (AC) | 50 V |
| Actuator Material | Liquid Crystal Polymer, Polymer, Polyphenylene |
| Housing Color | Beige |
| Contact Voltage Rating (AC) | 50 V |
| Contact Voltage Rating (DC) | 50 V |
| Contact Pitch | 0.5 mm |
